HAGER Lathe HDE250, Set
€5,190.00 €4,361.34
per set- Centre height 250 mm
- Distance between centres 1000 mm
- Engine power 1.5 kW (2 hp)
- Height 1225 mm
- Hollow spindle Ø 20 mm (#3 MT inner cone)
Description
Including infinitely adjustable outboard attachment (maximum turning diameter 850 mm) with height-adjustable supports extending to the floor, face plate Ø 250 mm with clamp ring for chase guard.
Specifications:
- Height of centre over bed 250 mm
- Distance between centres 1000 mm
- Speed ranges 150-450 / 400-1200 / 950-2900 rpm
- Hollow spindle Ø 20 mm (#3 MT inner cone) with M33 x 3.5 DIN 800 thread and four bearings, including chase guard
- Tailstock with #3 MT quill (150 mm travel) and measuring scale
- Face-milled lathe bed
- Underframe filled with quartz sand for additional damping of vibration
- Three-phase motor 400 V / 1.5 kW (2 hp)
- Power plug either 230 V or 400 V
- Working height/axis centre 1115 mm
- Length 1750 mm
- Width 600 mm
- Height 1230
- Weight 233 / 256 kg
- Tool rest 300 mm with 30 mm pin diameter
- Tool rest and tailstock with eccentric clamp
- #3 MT four-tooth spur driver Ø 24 mm
- #3 MT revolving centre
- Movable magnetic switch unit with toggle switch (anti-clockwise/clockwise rotation), potentiometer and emergency off
- Knockout rod
- Comes with German instructions
Properties
Locking Ring (ASR)
| Centre height: | 250 mm |
|---|---|
| Distance between centres: | 1000 mm |
| Engine power: | 1.5 kW (2 hp) |
| Height: | 1225 mm |
| Hollow spindle: | Ø 20 mm (#3 MT inner cone) |
| Mains connection: | 400 V |
| Morse taper: | #3 MT |
| Overall length: | 1800 mm |
| Speed: | 150-450 / 400-1200 / 950-2900 rpm |
| Speed control: | electronic speed control |
| Speed display: | digital |
| Tailstock: | #3 MT quill |
| Tailstock stroke: | 150 mm |
| Thread: | M33 x 3.5 DIN 800 |
| Tool support: | 300 mm |
| Typ: | Floor-standing lathe |
| Version: | Set |
| Weight: | 265 kg |
Properties
Locking Ring (ASR)
| Centre height: | 250 mm |
|---|---|
| Distance between centres: | 1000 mm |
| Engine power: | 1.5 kW (2 hp) |
| Height: | 1225 mm |
| Hollow spindle: | Ø 20 mm (#3 MT inner cone) |
| Mains connection: | 400 V |
| Morse taper: | #3 MT |
| Overall length: | 1800 mm |
| Speed: | 150-450 / 400-1200 / 950-2900 rpm |
| Speed control: | electronic speed control |
| Speed display: | digital |
| Tailstock: | #3 MT quill |
| Tailstock stroke: | 150 mm |
| Thread: | M33 x 3.5 DIN 800 |
| Tool support: | 300 mm |
| Typ: | Floor-standing lathe |
| Version: | Set |
| Weight: | 265 kg |
Accessories
Zubehör
Frequently bought together
Manufacturer
Hager Maschinenbau
With over 40 years of experience in the production of woodturning lathes, the German company HAGER has become one of the leading manufacturers. HAGER offers tailored special solutions in the field of woodturning, and stands for high-quality, functionally well thought-out products. The turning lathes are produced in accordance with DIN standards, and the long-term supply of spare parts and accessories is guaranteed. All accessories are compatible with all models.
