Stanley® Block Planes No. 9½
Product no.:
703001
Brand:
Stanley
€73.40 €61.68
per piece
Delivery time approx. 3-5 working days
- Blade thickness 2 mm
- Blade width 40 mm
- Design / cutting angle Bevel up / cutting angle 40°-45°
- Overall length 160 mm
- Plane body Grey cast iron
Description
For cuts with the grain. Blade angle 21°. Bevel angle 25°. Results in a normal cutting angle of 46°.
Grey cast iron block plane with ground sole and adjustable mouth opening. Cap iron clamped with eccentric lever. Lateral and depth adjustment. Planes can be upgraded with durable Japanese plane blades (No. 718073, 718075).
Stanley® Planes
Proven compact planes, adjustable mouth opening, easy to adjust lateral blade position, cutting depth. The blade is set bevel up (without a chipbreaker), which means that it is supported right up to the cutting edge, resulting in excellent vibration control. Grey cast iron body.
Properties
| Blade thickness: | 2 mm |
|---|---|
| Blade width: | 40 mm |
| Design / cutting angle: | Bevel up / cutting angle 40°-45° |
| Overall length: | 160 mm |
| Plane body: | Grey cast iron |
| Purpose: | Smoothing (fine finishing) |
| Typ: | Block planes |
| Weight: | 770 g |
Properties
| Blade thickness: | 2 mm |
|---|---|
| Blade width: | 40 mm |
| Design / cutting angle: | Bevel up / cutting angle 40°-45° |
| Overall length: | 160 mm |
| Plane body: | Grey cast iron |
| Purpose: | Smoothing (fine finishing) |
| Typ: | Block planes |
| Weight: | 770 g |
